22mm Mushroom Switch

Your Professional 22mm Mushroom Switch Supplier

We are a manufacturer of all kinds of pushbutton switches. From the factory - direct to the hands of consumers, here we save (total distribution-wholesalers-stores) and other channels, for you to provide a simple direct and effective supply! Besides our existing molded products, YongYuan also can production of products according to the drawings or samples from our customers.

Why Choose Us

24-Hour Service

Our dedicated 24-hour online support ensures prompt responses, providing you with an excellent shopping experience. Feel free to reach out with any questions at any time.

Professional technical support

We have an experienced technical team that can provide comprehensive technical support from product design and process optimization to maintenance.

Our Certificate

Under the strict management of ISO9001 quality system, environmental system ISO14001, the company's products have passed a series of international standard certificates such as UL, VDE, CCC, CE (LVD), CE (EMC).

Customized solutions

Every customer is unique, which is why we offer tailored solutions to meet your specific requirements. We offer technical support that is second to none.We take pride in our rapid response and flexibility to ensure your needs are met.

Advantages of 22mm Mushroom Switch

Versatile Design: The mushroom head design offers a distinctive and ergonomic push button experience.

Illuminated Options: Available with integral LEDs for clear indication in low-light conditions, enhancing visibility.

Spring Return Mechanism: Equipped with a spring return feature for quick and reliable reset after activation.

Latching Mechanism: Latching models are available for applications requiring a maintained state until actively reset.

Emergency Stop: Special models designed for emergency stop functions, ensuring safety and compliance with industrial standards.

Color Coding: A range of colors (Red, Green, Yellow, Blue, White, Black) for easy identification and signaling.

Durable Construction: Built to withstand harsh industrial environments with robust materials and finishes.

Product Description

Contact Types

N/O (Normally Open), N/C (Normally Closed), 1NO+1NC (Normally Open + Normally Closed), 2NO+2NC (2 Normally Open + 2 Normally Closed).

Circuit Voltage

24V/AC/DC for standard models, 220V/AC for neon and LED models.

Color Options

Red, Green, Yellow, Blue, White, Black.

Protection Ratings

Various models with different IP ratings to suit diverse environmental conditions.

Mounting

M22 threading for secure and easy installation.

Dimensions

Standard sizes with options for different panel cutouts (e.g., 40mm, 60mm).

Product Paramenters

Model NO.	Push button switch
Head shape	Flat head
Switch Combination	1NO
Operation type	Latching
Rated Current	10A
Shell material	Brass nickel,Stainless steel,aluminum oxide
Contact Resistance	50mΩ max
Insulation Resistance	1000MΩ Min
Dielectric Intensity	2000VAC
Accessories	Nut, Rubber Waterproof O-ring

Installation Guide for 22mm Mushroom Switch Head Push Button

Identifying the Right Location

The location must be easily accessible and visible during emergency situations.

Selecting the Right Button

Consider the application, environment, and regulations while choosing the right button.

Wiring Connections

Proper wiring is essential for the button’s functionality. Find detailed guidance here.

Testing

Conduct thorough testing to ensure that the button works correctly in all situations.

Providing Clear Labels

Proper labeling helps in quick identification during emergencies.

Key Features of 22mm Mushroom Switch

Ergonomic Design: Large, easily accessible actuator allows for quick and effortless operation, even with gloves.

Durable Construction: Made with high-quality materials to withstand harsh industrial environments and heavy use.

IP67/69K Rating: Offers excellent protection against dust and water, ensuring reliable performance in demanding conditions.

Versatile Mounting Options: Available in various mounting configurations, including panel and surface mount, for flexible installation.

High Visibility: Brightly colored actuators (typically red or yellow) ensure easy identification and rapid access in emergencies.

Multiple Contact Configurations: Available with various contact arrangements (e.g., NO, NC, NO/NC) to suit different control requirements.

Latching and Momentary Options: Provides both maintained (latching) and momentary action models for versatile application.

Maintain of 22mm Mushroom Switch

Routine Inspection: Regular checks for wear, damage, or malfunctions help in early detection of issues.

Cleaning: Use appropriate cleaning agents and methods that won’t harm the materials or electrical components.

Replacement of Damaged Parts: Timely replacement of worn or damaged parts prevents further deterioration.

Adherence to Manufacturer Guidelines: Always follow the guidelines provided by the manufacturer for maintenance and cleaning.

Professional Maintenance: Consider periodic professional inspections and maintenance for optimal performance.

Applications of 22mm Mushroom Switch

Industrial Mainstays

In manufacturing, mushroom head buttons are prevalent on assembly lines, precisely controlling critical equipment like conveyor belts and robotic arms. Their robust design ensures stable operation, even in harsh conditions, meeting continuous production demands. They are also ubiquitous on control panels for heavy machinery and cranes, where their prominent design aids operators in rapid location, significantly enhancing operational safety.

Human-Machine Interaction Aids

Beyond industrial applications, mushroom head buttons are also essential in devices like gaming machines and ticket vending machines. They serve as intuitive user control interfaces, providing satisfactory tactile feedback and ensuring operational accuracy.

Shipping

productcate-881-494

FAQ

Q: Why would an emergency stop button have a mushroom head?

A: Red pushbuttons can also have large heads (called mushroom heads) for easy operation and to facilitate the stopping of a machine. These pushbuttons are called emergency stop buttons and for increased safety are mandated by the electrical code in many jurisdictions.

Q: How do you choose the right stop button?

A: So, when you're picking a button, it's super important to go for one that meets or even exceeds safety standards like IEC 60947-5-5. And don't forget—these buttons should be eye-catching and super easy to get to, so you can hit them without wasting any time when things go south.

Q: What is a mushroom head switch?

A: Mushroom-style pushbuttons feature an oversized head that allows quick and easy activation, even while wearing gloves. Operator head sizes from 35mm to 65mm. Illuminated and non-illuminated models. Momentary, twist-to-release, or maintained actions.

Q: Can emergency stops be bypassed?

A: The most reliable form of emergency stop button is where the power cord feeds through it and the circuit is broken by pressing the button. In that case, removing the button and connecting the two halves of the power cord directly together would bypass it.

Q: What are common stop button failures?

A: Proper troubleshooting of Emergency Stop Buttons is essential to maintaining a safe and compliant work environment. Common issues with E-Stops include worn-out E-Stop Push Button Heads, faulty Push Button Contact Blocks, and improper wiring.

We're professional 22mm mushroom switch manufacturers in China, providing customized 22mm mushroom switch for sale. Feel free to wholesale 22mm mushroom switch and get quotation from our factory.
