1. Specifications
1. Panel cutout: 16mm
2.Rating: 0.5A/220VAC
3.Contact configuration: 1NO1NC
4.Led color and voltage:
R,G,B,O,Y,W 6color for you choos,
From 1.8V to 230V led voltage for you choose.
5.Protection Class: IP65,Ik08
6.Pin terminal:2.8*0.5mm
7.Panel thickness: 1-8mm
8.Mechnical life:500,000 times
9.Electrical life:50,000 times
10.Actuator: stainless steel and chrome plated brass, black brass
11.Body:stainless steel and chrome plated brass, black brass
12. Approval: CE,LVD, ROHS,CCC. compliant
13.Switch function: momentary or latching for you choose
2. Drawing :
3. Tri-color lampe rating:
4. Performance Characteristic：
Operating Temperature | -25℃~+55℃（no freezing） Keep the air flowing |
Operating Humidity | 45~85%RH(no condensation) |
Contact Resistance | ≤50mΩ |
Insulation Resistance | ≥1000MΩ |
Dielectric Strength | 1500V, AC 50Hz, 60 seconds |
Vibration Rasistance | 50Hz，Amplitude about 1.2mm |
Shock Rasistance | ≥10g |
Solder Heat Resistance | 320℃（or 30W soldering iron）no more than 2 seconds |
5. Switch Ratings:
Rated Insulation Voltage Ui | 250V | |||||
Rated voltage | 12V | 24V | 110V | 220V | ||
Rated Operation Curremt | AC 50/60Hz | Resistive load | 1A | 0.5A | ||
Inductive load | 0.7A | 0.5A | ||||
DC | Resistive load | 1A | 1A | 0.2A | ||
Inductive load | 0.7A | 0.7A | 0.1A | |||
Contact material | Silver Alloy | |||||
Minimum load: 3VAC/DC, 5mA(Reference)
PS: Application scope depends on operating environment and load type
6. Application
In the past, the pushbutton switches always used In Industrial. But now more and more used in home applications.
For example：
Industrial：
Home Applications：
7. Picture about factory:
FAQ:
Q: What about the Shipment?
A: Ship worldwide by sea, by air, EMS, DHL, FEDEX, UPS, TNT etc. (EXPRESS: around 5-8 working days to arrive; International AIR Mail: around 2-4 weeks to arrive.)
We often ship item in 3-5 business days. For mass prodution is about 10~15 days.
Q. What is your terms of packing?
A: Generally, we pack our goods in neutral boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
