1. Product description
Model Number: LAS1-AM-□Z/△/▲/◎
Panel cutout dimension: Φ16mm
Mushroom head(easier to operate)
Switch Rating: AC220V/0.5A, DC110V/0.1A
Contact: 1NO1NC / 2NO2NC
Latching
IP40 / IP65
Mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
Contact resistance: ≤ 50mΩ
2. Drawing :
3. Lead time: 1000pcs/10workdays
Payment: TT/PAYPAL before shipment.
Shipping method: air forwarder, sea forwarder, Express
4.About ONPOW:
Speciallized in the field of pushbutton switch and indicator for more than 30 years, we put forward 1 or 2 series of new product each years. And our products are welcomed at home and abroad
5.Picture about factory:
Our Service&Promise
Q1. Can I have a sample order for Switch?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than 1000pcs
